HK-968 V3 Aluminum-wood integrated edge banding machine
Product Features
Touchscreen
Simple operation
Diamond pre-milling
Pre-milling can remove burrs and uneven parts on the edge of the board, which is beneficial to the bonding of the edge banding strip and the board and improves the firmness of the edge banding.
Glue 1
The glue pot can ensure that the glue is evenly applied to the surface of the edge banding, thereby improving the bonding quality and firmness of the edge banding.
Five rounds of pressing
Pressing can provide more uniform pressure distribution, ensuring a close bond between the edge banding and the board, thereby improving the quality and firmness of the edge banding.
Glue 2
The glue pot can ensure that the glue is evenly applied to the surface of the edge banding, thereby improving the bonding quality and firmness of the edge banding.
Pressing configuration
Five-wheel pressing, four-wheel pressing 1, four-wheel pressing 2
Rough trimming + fine trimming
A high-frequency motor structure with automatic tracking of large and small discs is used to trim the edge banding strips bonded on the upper and lower sides of the board and remove excess edge banding strips.
Scrape edge 1+Scrape edge 2
Double scraping can ensure the cleanliness and flatness of the board edge, avoiding impurities or unevenness during edge sealing, thus improving the quality of edge sealing
End trimming
With automatic pressure relief valve, accurate and no knocking, double guide rail structure and three motors in parallel can reduce vibration and deviation during processing, and improve processing stability and reliability
Four comer track trimming
Four comer track trimming，More precise chamfering can be achieved, ensuring the consistency and accuracy of the chamfering.
Flexible flat scraper
Flexible flat scraper can better adapt to the uneven surface of the board and ensure the flatness and quality of the edge banding.
Double polishing
Polishing can make the edge banding surface smoother and more delicate, improving the appearance quality and aesthetics of the product.
All images are for illustrative purposes only and serve as a reference to illustrate the equipment items.
HK-968-V3 Heavy duty aluminum-wood integrated edge banding machin
Technical parameters
| Model | HK-968-v3 |
|
Overall dimension |
10100*745*1735mm |
|
Sheet width |
100mm or more |
|
Minimum processing length |
150mm |
|
Work Form |
Fully automatic |
|
Edge banding machine |
0.4-1.5mm |
|
Feed speed |
20-26m/min |
|
Rated air pressure |
5300L*5950W*1900H(mm),380V/50HZ |
|
Total Power |
35.99kw |
|
Conveyor motor |
7.5k |
